AK100 Slope Reinforcement Portable Anchor Drilling Rig with
Stepless Shift Hydraulic Drive
JCDRILL Portable Drill Rig
AK100 portable anchoring drilling rig is a complete hydraulic power
head machine. It applies to the construction of big tonnage stress
anchoring hole for water power station, railway, highway, drainage
hole and geologic calamity fathering for landslide prevention and
rock collapse. It is also used to drill small size water well and
high-pressure jet grouting hole.
Application
Charactaristic
1. It has great drilling capability, wide range of application ,
rapid drilling speed and high drilling efficiency, as well as
powerful ability of eliminating accident.
2. Extension mechanism in the output spindle of top drive power
head protects drilling tools
effectively. It can increase the hole inclination angle range and
drill elevation angle hole, while setting the top drive power head
and hole top plate toward the
opposite direction.
3. A set of front-mounted adjustable columns on drill frame is used
for adjusting the height of mast front-end, which makes it
convenient to align with working position.
4. Rig structure is separate group design, it assures good
disassembility , rapid and convenient mount and transport, best
working environment and lower labor strength as well as remote
control and
operation.
5. Rig structure is separate group design, it assures good
disassembility , rapid and convenient mount
and transport, better working environment and lower labor strength
as well as remote control and operation.
6. The imported hydraulic motor, other main assembly preferentially
selected home made reputed and high quality products ensure its
stable running performance, reliable product quality and long
service life.
It has good interchangeability due to the high grade of
standardization and seriesization of wearing parts.
7. Full hydraulic drive and operate, stepless shift, simple
operate, convenient maintain and few wearing parts.
8. It can be used with various drilling method such as carbide bit
drilling, anger drilling, DTH hammer drilling, follow-up casing
drilling etc.
Specification
| Drilling depth | 60-120m |
| Drilling diameter | ¢ 250- ¢ 110mm |
| drill diameter | ¢ 114 × 1500, ¢ 89 × 1500 (mm) |
| Drilling dip | 0-180 ° |
| Power head output speed (positive and negative) | 5-42 (low) r / min 5-90 (upscale) r / min |
| Rated output torque of the power head | 6000NM |
| Power head stroke | 1800 mm |
| Mast slip stroke | 500 mm |
| Power head lifting force | 55KN |
| Power Head biggest feeding force | 40KN |
| Hydraulic system rated pressure | 18Mpa |
| Motor Power | 37KW |
| Host Dimension | 3450 × 1750 × 1500 (mm) |
| Rig weight | 2500Kg |
| Maximum disintegration weight | 300Kg |
